Product Name
JX01S Semi-automatic Smart Lever Lock
Material
- Lock Housing: Aluminum Alloy
- Touch Panel: Tempered Glass
- Surface Treatment: Spray Painting Process
Function
- Unlock Methods: Fingerprint, Password, IC Card, Mechanical Key
- Optional:TUYA Wifi / TT Lock APP Remote Control & Remote Controller
- Dummy anti-peep code function
- Low power alert reminder
- Error operation warning
- Anti-break alarm(Optional)
- Anti-static & Anti-electromagnetic Interference (Anti-hacking protection)
- Type-C USB emergency power supply, Support Power Bank Emergency Unlock
- Language: Chinese / English
Specifications
- Model: JX01S
- Lock Type: Semi-automatic Smart Lever Lock, support long handle & short handle
- Lock Cylinder: Class C
- Power Supply: 4 PCS AAA Batteries
- Working Voltage: 4.5–6.5V
- Applicable Door Thickness: 40–120 mm
- Suitable Mortise: 2085/2885/3585/4585 and multiple sliding lock bodies (with hook / without hook)
- Panel Dimension: Front 337*37*65 mm | Back 337*37*65 mm
- Color Option: Black, Silver, Golden
- Waterproof Grade: IPX5
- Working Temperature: -30℃ ~ 60℃
- Working Humidity: 20%–93%
- Fingerprint Performance: FRR＜0.1%; FAR＜0.005%
- User Capacity Fingerprint:100 Groups | Password:199 Groups | IC Card:199 Groups
- Single Set Net Weight: ≈1.66 KG
- Single Set Gross Weight: ≈2.38 KG (without mortise)
- Single Box Size: 445*195*115 mm
- Carton Spec: 10 units/carton; Carton size 59*47*41 cm; Empty carton weight:1.3 KG/PCS
Standards
- Pass Anti-static Test
- Support anti-electromagnetic interference (EMI)
- IPX5 waterproof rating
- Equipped with Class C anti-pick security lock cylinder
Application
- Suitable for wooden doors, security doors, metal doors with thickness 40–120 mm
- Scenarios: private residences, apartments, rental houses, villas. IPX5 waterproof allows installation under covered outdoor gateways.
Key Advantages
- Zinc alloy body + tempered glass touch panel, sturdy structure and premium appearance
- Multiple color options: Black, Silver, Golden to match various door styles
- IPX5 waterproof performance, suitable for sheltered outdoor entrance doors
- Optional long handle / short handle to satisfy different door installation requirements
- Ultra-long service life: handle opening lifetime ≥100,000 times; battery supports 5000 normal openings
- Two optional intelligent solutions: TUYA Wifi or TT Lock APP remote management
- Powerful compatibility, supports dozens of sliding lock body models
- Wide working temperature range (-30℃~60℃), adapts to frigid and high-temperature regions
- Type C emergency power supply to avoid lockout caused by exhausted batteries
Customization / OEM Service
- Custom housing color and spray painting surface treatment
- Optional PCB mainboard: TUYA Wifi or TT Lock solution
- Remote control can be added as optional accessory
- Laser engraving customer logo on lock panel and packages
- Custom user manual, color box and outer carton design
- Function parameter adjustment to meet different regional market demands
